Photo is representative
General Purpose Relay 48V DC 8 Pin 2CO 10A IP20
Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.
Product Information
Stock Code
8P48VDC
GTIN
—
Stock status:
In stock
priced individually
More arriving soon
Net price: £11.94
Gross price
£14.33
Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns
Mon‐Fri · Subject to order volume Free delivery available 30 day returns
8-pin plug-in general purpose relay from the RUB series. Designed for industrial control applications — panel boards, HVAC, motor control, and automation circuits.
Features a non-polarity LED indicator (red for AC, blue for DC) and a lockable test button with inspection window. 48V DC coil with no polarity sensitivity makes wiring straightforward.
- Contact rating: 10A resistive / 7A inductive at 250VAC
- DPDT (2CO) contact configuration
- Pick-up voltage: ≤80% of rated; drop-out: ≥10% DC / ≥30% AC
- Operate time ≤30ms, release time ≤20ms
- Operating temp: -10 to +55°C
