6491B Single Core LSZH H07Z-R 2.5mm² Brown 450 750V

Photo is representative

6491B Single Core LSZH H07Z-R 2.5mm² Brown 450 750V

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 2.5PVCBROWN1
GTIN —
Stock status: In stock

priced per meter

More arriving soon

Net price: £0.53

Gross price

£0.64

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

Single-core 6491B rated H07Z-R for conduit and fixed protection installations. LSZH sheath — use where smoke, toxic fumes, or halogen emissions are a concern: plant rooms, public buildings, enclosed spaces.

Suited to lighting circuits, switchgear, and appliance wiring.

  • 2.5mm² Class 2 stranded copper, 7⁄0.67 stranding
  • 450/750V rated, +90°C max operating temp
  • OD 3.65mm, minimum fixed bend radius 6 × OD
  • Flame retardant to BS EN 60332-1-2
  • BS EN 50525-3-41 | H07Z-R | IEC/EN 61034-1⁄2
Specifications

Conductor Size

2.5mm²

Number of Cores

1

Stranding

7/0.67

Conductor Type

Class 2 stranded copper

Voltage Rating

450/750V

Temperature Range

0°C to +90°C

Overall Diameter

3.65mm

Sheath Material

Low Smoke Zero Halogen (LSZH)

Minimum Bending Radius (Fixed)

6 × overall diameter

Flame Retardancy

BS EN 60332-1-2

Core Colour

Brown

Weight

33 kg/km

Standard

H07Z-R, BS EN 50525-3-41, BS EN/IEC 60228, IEC/EN 61034-1/2, BS EN/IEC 60332-1-2
