4 Core 0.75mm² H05Z1Z1-F LSZH Flexible Cord 300 500V White Sheath

Photo is representative

4 Core 0.75mm² H05Z1Z1-F LSZH Flexible Cord 300 500V White Sheath

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 475PVC3PH
GTIN —
Stock status: In stock

priced per metre

More arriving soon

Net price: £0.87

Gross price

£1.05

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

4-core LSZH flexible cord to H05Z1Z1-F (3184B). Zero halogen insulation and sheath — suited to indoor wiring in public areas where smoke and fume toxicity matters: hospitals, shopping centres, airports.

Typically used for pendant lighting and general supply leads.

  • 0.75mm² Class 5 stranded copper, 24⁄0.20mm stranding
  • Core colours: Brown, Black, Grey, Green/Yellow — white outer sheath
  • 300/500V rated, 7.7mm OD
  • Flame retardant to BS EN 60332-1-2
  • Standards: H05Z1Z1-F, BS EN 50525-3-11, BS EN/IEC 60228
Specifications

Voltage Rating

300/500V

Conductor Size

0.75mm²

Number of Cores

4

Conductor Type

Class 5 flexible stranded copper

Stranding

24/0.20mm

Insulation Material

Low Smoke Zero Halogen (LSZH)

Sheath Material

Low Smoke Zero Halogen (LSZH)

Sheath Colour

White

Core Colours

Brown, Black, Grey, Green/Yellow

Overall Diameter

7.7mm

Weight

85 kg/km

Minimum Bending Radius

5 x overall diameter

Temperature Range

-5°C to +70°C

Flame Retardancy

BS EN 60332-1-2

Standards

H05Z1Z1-F, BS EN 50525-3-11, BS EN/IEC 60228, BS EN/IEC 60332-1-2
