6491B Single Core 2.5mm2 LSZH Blue H07Z-R 450 750V 100m

Photo is representative

6491B Single Core 2.5mm2 LSZH Blue H07Z-R 450 750V 100m

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 2.5PVCBLUE1
GTIN —
Stock status: In stock

priced per metre

More arriving soon

Net price: £0.54

Gross price

£0.65

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

6491B single core 2.5mm² LSZH cable in blue. For use in conduit and fixed protection installations, lighting circuits, switchgear, and appliances.

LSZH sheath makes it suitable where fire, smoke, and toxic fumes are a concern — plant rooms, public buildings, enclosed spaces.

  • 2.5mm² Class 2 stranded copper, 7⁄0.67 construction
  • 450/750V rated, 0°C to +90°C operating range
  • OD 3.65mm, min fixed bend radius 6 × OD
  • Flame retardant to BS EN 60332-1-2
  • Standards: H07Z-R, BS EN 50525-3-41
Specifications

Conductor Size

2.5mm²

Number of Cores

1

Core Colour

Blue

Conductor Type

Class 2 stranded copper

Stranding

7/0.67

Voltage Rating

450/750V

Temperature Range

0°C to +90°C

Sheath Material

LSZH (Low Smoke Zero Halogen)

Overall Diameter

3.65mm

Min Bending Radius (Fixed)

6 × overall diameter

Weight

33kg/km

Flame Retardancy

BS EN 60332-1-2

Standard

H07Z-R, BS EN 50525-3-41, BS EN/IEC 60228, IEC/EN 61034-1/2, BS EN/IEC 60332-1-2
