PCE 63A 2P+E IP67 Industrial Plug - 230V Blue POWER TWIST

Photo is representative

PCE 63A 2P+E IP67 Industrial Plug - 230V Blue POWER TWIST

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 033-6
GTIN —
Stock status: 1 in stock

priced individually

Net price: £44.16

Gross price

£52.99

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

PCE POWER TWIST 63A 2P+E CEE plug for 200–250V AC distribution. IP67 rated, 6h clock position, straight angle configuration.

PA6 polyamide housing with nickel-plated CuZn brass contacts including pilot pin. Screw-terminal connection with gland nut cable entry.

  • Terminal capacity: 6–16mm²
  • Cable diameter: 14.5–36mm
  • IK09 impact rating
  • Operating temp: -25°C to +40°C
  • Rated to EN 60309-2, 230V blue
Specifications

Current Rating

63A

Configuration

2P+E (3 pole)

Clock Position

6h

Voltage

200–250V AC, 230V Blue

Frequency

50+60 Hz

IP Rating

IP66/IP67

IK Rating

IK09

Housing Material

PA6 polyamide

Contact Material

CuZn brass, nickel-plated

Terminal Capacity

6–16mm²

Cable Entry Diameter

14.5–36mm

Operating Temperature

-25°C to +40°C

Standards

EN 60309-2

Documents

datasheet 033-6 Datasheet
