Front view Schneider TeSys K LC1K1210P7 12A 230V AC mini contactor

Photo is representative

Schneider TeSys K 12A 230V AC 3P Mini Contactor - LC1K1210P7

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code LC1K1210P7
GTIN 3389110856910
Stock status: 6 in stock

priced individually

More arriving soon

Net price: £40.14

Gross price

£48.17

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

Schneider TeSys K 12A 230 V AC 3-pole mini contactor (LC1K1210P7) for control and switching of resistive and motor loads. Compact K-frame design for space-critical installations; screw clamp terminals for secure wiring and plate or 35 mm DIN-rail mounting. Rated AC-3/AC-3e for motor control (12 A at ≤440 V) and AC-1 (20 A at ≤690 V). Supplied with one instantaneous auxiliary contact (1 NO). Conforms to IEC/EN 60947-4-1 and relevant UL/CSA standards.

Specifications

Current Rating

12 A (AC-3/AC-3e at ≤440 V); 20 A (AC-1 at ≤690 V)

Control Coil

230 V AC, 50/60 Hz (P7)

Contact Configuration

3 power poles (3 NO) + 1 instantaneous auxiliary (1 NO)

Frame Size

TeSys K (mini)

Terminal Type

Screw clamp terminals — 1.5…4 mm² solid; 0.75…4 mm² flexible without ferrule; 0.34…2.5 mm² flexible with ferrule

Mounting Method

Plate or 35 mm DIN rail

Motor Ratings (AC-3)

3 kW at 220–230 V; 5.5 kW at 380–415 V; 5.5 kW at 440 V; 4 kW at 690 V

Utilisation Categories

AC-3, AC-3e, AC-1, AC-4

Inrush / Hold Power

Inrush 30 VA; Hold-in 4.5 VA (at 20 °C)

Electrical Durability

1.3 M cycles (12 A AC-3 at ≤440 V)

Mechanical Durability

10 million cycles

Rated impulse withstand voltage

8 kV

Rated short-time withstand (Icw)

115 A (50 °C, 1 s) for power circuit; see datasheet for additional time ratings

Rated breaking/making capacity

Rated breaking: 110 A at 440 V (IEC 60947); Rated making: 144 A (power circuit)

Associated fuse rating

25 A gG / 25 A aM (power circuit) at ≤440 V; 10 A gG (signalling)

Insulation / Ui

Power circuit: 690 V (IEC), 600 V (UL/CSA); Signalling: 690 V (IEC)

Operating rate

Up to 3600 cycles/h

Operating temperature / Storage

Storage: -50…80 °C; Operating altitude up to 2000 m without derating

Dimensions (H×W×D)

58 × 45 × 57 mm

Weight (net)

0.18 kg

Standards & Approvals

EN/IEC 60947-4-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, CB, CCC, UL, CSA, EAC, CE, UKCA

IP / Protection

IP2X (VDE 0106)

Mechanical shock & vibration

Shocks up to 15 Gn; vibrations 2–5 Gn (see datasheet for axis-dependent values)

Safety reliability (B10d)

B10d = 1,369,863 cycles (nominal load); 20,000,000 cycles (mechanical load) per EN/ISO 13849-1

Warranty

18 months
